Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn

Name: Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn
Rating: 5 (99 reviews)

Product Description
hydraulic adaptor metric male O-Ring flat sealing pipe fittings

Material: Carbon Steel, Stainless Steel
Surface Treatment: White or Yellow Zinc-Plated
Standards: Eaton, DIN, ISO, SAE, JIC or As customers' drawing
Export Markets: Global

Get A Quote

PREV：Hydraulic Pipe Fittings / 4c / 4D / Metric Male Thread Hydraulic Plug
بعدی：Reducer Tube Adaptor with Swivel Nut

Specification
Contact Us

Standard:	DIN
Material:	Medium Carbon Steel
Connection:	Female
Surface Treatment:	Galvanized Sheet
Head Type:	Round
Manufacturer:	Factory

PART NO.	THREAD E,G	THREAD F	TUBE O.D. D1,D3	TUBE O.D. D2	DIMENSIONS I1,I3	DIMENSIONS L1,L3	DIMENSIONS L2	DIMENSIONS S1	DIMENSIONS S2,S4	DIMENSIONS S3	MPa
PART NO.	THREAD E,G	THREAD F	TUBE O.D. D1,D3	TUBE O.D. D2	DIMENSIONS I1,I3	DIMENSIONS L1,L3	DIMENSIONS L2	DIMENSIONS S1	DIMENSIONS S2,S4	DIMENSIONS S3	MPa
BC-12	M12×1.5	M12×1.5	6	6	12	27	26	12	14	14	31.5L
BC-14	M14×1.5	M14×1.5	8	8	14	29	27.5	12	17	17
BC-16	M16×1.5	M16×1.5	10	10	15	30	29	14	19	19
BC-18	M18×1.5	M18×1.5	12	12	17	32	29.5	17	22	22
BC-22	M22×1.5	M22×1.5	15	15	21	36	32.5	19	27	27
BC-26	M26×1.5	M26×1.5	18	18	23.5	40	35.5	24	32	32
BC-30	M30×2	M30×2	22	22	27.5	44	38.5	27	36	36	16L
BC-36	M36×2	M36×2	28	28	30.5	47	41.5	36	41	41
BC-45	M45×2	M45×2	35	35	34.5	56	51	41	50	50
BC-52	M52×2	M52×2	42	42	40	63	56	50	60	60
BD-14	M14×1.5	M14×1.5	6	6	16	31	27	12	17	17	63S
BD-16	M16×1.5	M16×1.5	8	8	17	32	27.5	14	19	19
BD-18	M18×1.5	M18×1.5	10	10	17.5	34	30	17	22	22
BD-20	M20×1.5	M20×1.5	12	12	21.5	38	31	17	24	24
BD-22	M22×1.5	M22×1.5	14	14	22	40	35	19	27	27
BD-24	M24×1.5	M24×1.5	16	16	24.5	43	36.5	24	30	30	40S
BD-30	M30×2	M30×2	20	20	26.5	48	44.5	27	36	36
BD-36	M36×2	M36×2	25	25	30	54	50	36	46	46
BD-42	M42×2	M42×2	30	30	35.5	62	55	41	50	50
BD-52	M52×2	M52×2	38	38	41	72	63	50	60	60	31.5S
"RN", BC-30RN. Note: In case if you are interested to order the adapter in complete set with cutting ring and nut, it is necessary to insert suffix "RN" after our part NO.,for example BC-30RN
